Measuring Range (MPa•sec): | 80~40,000,000 | Rotary Speed (Revolutions/minute): | 0.1 ~ 99.9 (variable Speed) |
---|---|---|---|
Display: | English Operation Screen | Power: | 220V/110V |
Name: | Viscosímetro Brookfield Digital | Power: | Input 100~240V 50~60Hz |
Highlight: | Rotary viscosímetro brookfield digital,viscosimetro digital brookfield,lab dv1 digital viscometer |
RVDV-1 Digital Display Rotary Viscometer / Brookfield Laboratory Viscometer
Main Specifications
Measuring range (MPa·sec) | 80~40,000,000 |
Rotary speed (Revolutions/minute) | 0.1 ~ 99.9 (variable speed) |
Rotor configuration | R2,R3,R4,R5,R6,R7 each one |
Measurement error | ±1 %(FS)Newtonian fluid |
Repeatability | ±0.5 %(FS)Newtonian fluid |
power supply |
Dedicated power adapter (Input 100~240V 50~60Hz) |
Display function | The LCD screen can display viscosity, speed, temperature, percent torque, rotor number, and the maximum viscosity value of the selected rotor that can be measured at the current speed, etc. |
Standard configuration parts
·Host machine | 1 | ·Lifting frame and lifting mechanism | 1 |
·Protection frame | 1 | ·Special power adapter | 1 |
·Rotor | 1 | ·Wrench | 1 |
·Base and leveling feet | 1 | ·RTD temperature probe | 1 |
·RS232 standard output interface | 1 |
Excellent Pre-sale service
1. According to your specification request, provide the best price for you.
2. After you confirmed the specification and price, our engineers and sales will make a Official Quotation for you confirm.
3. After our Finance Department confirmed your deposit, we will start manufacture the products for you.
4. Update the progress of production to you in time, to help you know your order details progress
5. After the product manufacture finished, if you need, we will arrange shipping for you. With our professional skill, you just need to pick your products up at the destination place, and don’t need to worry about the shipping at all.
Outstanding After-sale service
1. 12 months guarantee term, and Professional Technical Support.
2. If you have any questions when you use our products, please tell us, we will help you solve the problems in time.
3. If any spare parts have problem after you used it, we can provide it for you, help you solve the problem if anything affect your business.
4. We can also provide engineer to your local place if you need. You just need to bear the Airplane ticket, and accommodation cost.
5. Other relevant service you request.
