BN-8627 Corrugated Crush Test Concora Medium Fluter CMT CCT Test

Basic Information
Place of Origin: Wuhan, China
Brand Name: BonninTech
Certification: CE, ISO
Model Number: BN-8627
Minimum Order Quantity: 1 set
Price: USD3000-6000/set
Packaging Details: Standard export carton box
Delivery Time: 5-10 days
Payment Terms: T/T
Supply Ability: 200 sets/month
Equipment: Concora Medium Fluter Standard Sample: 150 To 160 X 12.7 Mm
Warranty: 12 Month, Life-time Technical Support

This BN-8627 Concora medium fluter is used for sample preparation for concora medium test (CMT) and corrugated crush test (CCT). It is specially used for making standard corrugating samples which used to determinate of flat crush strength of corrugated paper when pressed standard waveform. It’s an indispensable instrument for judging the quality and performace of corrugated fibreboard and corrugated boxes in the packaging industry.



Test Standards:

CMT Test ISO 7263, DIN 53 143, SCAN P27, TAPPI T 809, APPITA/ AS 1301.434S, UNE 57.074, PAPTAC D29
CCT Test SCAN P42, TAPPI T843, UNE ISO 16945



Principle:

Standard samples of 150 to 160 x 12.7 mm ± 0.1 mm are prepared and having prefixed theworking temperature in the Grooving Machine to 177 ºC between the corrugating discs, thesample is introduced through the upper inlet in the vertical model and front in the horizontalmodel, and after forming the corrugated sample is collected carefully, so as not to transfer moisture with your hands.



Main Features:

1.The high-precision temperature controller can adjust the temperature accurately, and the PID control mode with automatic temperature compensation mode is adopted.

2.Fast response and high steady-state accuracy.

3.Digital display of actual temperature and set temperature, with over temperature protection device, automatic memory of set parameters after power failure, with parameter self-tuning function.

4.The precision machined copper gear has large heat capacity, good heat transfer and wear resistance. The standard button is sensitive and durable, and the automatic corrugated base paper is corrugated.



Technical Specifications:

Radius of teeth at peak 1.50 ± 0.10mm
Radius of teeth at base 2.00 ± 0.10mm
Depth of teeth 4.75 ± 0.05mm
Distance between teeth 8.55 ± 0.05mm
Diameter of rolls 228.5 ± 0.5mm
Dimensions of rolls 16 ± 1mm
Standard working speed 4.5r/min
Working temperature range RT~200℃
Temperature accuracy ±1℃
Standard working temperature 175±8℃, also based on your requests
Working pressure range optional 49~108N
Machine Dimensions 530*400*475mm
Machine Weight About 50kg
Power supply 220V 50HZ or customized



BN-8627 Corrugated Crush Test Concora Medium Fluter CMT CCT Test 0

BN-8627 Corrugated Crush Test Concora Medium Fluter CMT CCT Test 1
FAQ 1. Are you a factory or trading company?
We are a factory.

FAQ 2. Can you supply OEM?
OEM is available.

FAQ 3. What's the MOQ ?
(1). MOQ is 1 piece. The disposable supplies order usually at least 1 box.

FAQ 4. How about the order processing and lead time?
After order confirmation and receive the advance payment, we will prepare the machines and goods. Usually could ready within 10 working day, when dispatch, will inform client and send the documents for client making import customs clearance.

FAQ 5. What quality will be ensured?
100% new and quality inspection before delivery from factory.
Stable export box for good package.

FAQ 6. Can you guide the working?
The machine will deliver with English display, English manual and video for installation and operation.

FAQ 7. How can your engineer replace parts if they are not beside the machine?
Bonnin’s engineer could provide the solutions by email and video. In warranty period, we can send spare parts for free and life-time technical support for spare supply.
