120W Automatic Melting Point Apparatus Device RS232 USB Interface Lab Testing Instruments

Basic Information
Place of Origin: Wuhan, China
Brand Name: BonninTech
Certification: CE, ISO
Model Number: JH Series
Minimum Order Quantity: 1 set
Price: USD2000-8000/set
Packaging Details: Standard export carton box
Delivery Time: 5-10 days
Payment Terms: T/T
Supply Ability: 200 sets/month
Display: Touch Screen Functions: Automatically Records The Melting Curve
Temperature: Room Temperature ~ 400 ℃ Warranty Time: 12 Months And Life-time Technical Support
High Light:

RS232 melting point device

,

USB melting point determination apparatus

,

120W automatic melting point apparatus

BONNIN Automatic Camera Video Melting Point Apparatus Automatic Melting Point Tester FDA CFR21

Automatic Digital Camera Video Melting Point Tester FDA CFR21



This automatic melting point apparatus is perfectly combined with high-precision temperature control technology and high-definition video camera technology, which not only provides users with accurate, stable and reliable test results, but also provides users with efficient and convenient test experience. The high-definition video can easily and clearly see the whole process of melting and boiling of the sample, and automatically detect the real-time spectrum display, which is convenient for the user to accurately measure the melting point, boiling point, turbidity point and slip point of the sample.



Field of use

Melting point instrument plays an important role in chemical industry and medical research, and is an indispensable instrument for producing food, medicine, spices, dyes and other organic crystal substances.



Features

1, HD video replaces traditional microscope;

2, 4 samples were processed at a time (3 small 1 large holes);

3, High automation integration to achieve one-button measurement function;

4, Fully automatic recording of melting range, initial melting, final melting;

5, melting point, boiling point, cloud point, slippage;

6, Equipped with a high-definition camera lens module.



Technical parameters:

Model JH30 JH50
Temperature range RT-350℃ RT-400℃
Detection method Semi-automatic Semi-automatic
Capacity per batch 4pc./batch 4pc./batch
Temperature resolution 0.1℃ 0.1℃
Temperature gradients (0.1-20.0)℃/Min (0.1-10.0)℃/Min
Temperature accuracy ±0.3℃ ±0.3℃
Repeatability 0.1℃/Min ±0.1℃ 0.1℃/Min ±0.1℃
Camera&Video Camera Camera&Video
Video playback YES
Operator account 8
Result storage 200 400
SD card capacity 8G 8G
Display TFT Touch screen TFT Touch screen
Interface USB RS232 SD card Enternet USB RS232 SD card Enternet
Opening capillary size

I.D>1.0mm,O.D.1.4mm

Double opening

I.D>1.0mm,O.D.1.4mm

Double opening

Power 110-220V 50/60HZ 120W 110-220V 50/60HZ 120W



Model JH70 JH90
Temperature range RT-350℃ RT-420℃
Detection method Fully automatic(compatible with Semi-automatic) Fully automatic(compatible with Semi-automatic)
Capacity per batch 4pc./batch 4pc./batch
Temperature resolution 0.1℃ 0.1℃
Temperature gradients (0.1-20.0)℃/Min (0.1-20.0)℃/Min
Temperature accuracy ±0.3℃ ±0.3℃
Repeatability 0.1℃/Min ±0.1℃ 0.1℃/Min ±0.1℃
Camera&Video Camera Camera&Video
Video playback NO YES
Operator account 8 20
Result storage 400 1000
SD card capacity 8G 32G
Display TFT Touch screen TFT Touch screen
Interface USB RS232 SD card Enternet USB RS232 SD card Enternet
Opening capillary size I.D.1.0mm,O.D.1.4mm I.D.1.0mm,O.D.1.4mm
Power 110-220V 50/60HZ 120W 110-220V 50/60HZ 120W



120W Automatic Melting Point Apparatus Device RS232 USB Interface Lab Testing Instruments 0



120W Automatic Melting Point Apparatus Device RS232 USB Interface Lab Testing Instruments 1120W Automatic Melting Point Apparatus Device RS232 USB Interface Lab Testing Instruments 2

120W Automatic Melting Point Apparatus Device RS232 USB Interface Lab Testing Instruments 3

FAQ 1. Are you a factory or trading company?

We are a factory.



FAQ 2. Can you supply OEM?

OEM is available.



FAQ 3. What's the MOQ ?

(1). MOQ is 1 piece. The disposable supplies order usually at least 1 box.



FAQ 4. How about the order processing and lead time?

After order confirmation and receive the advance payment, we will prepare the machines and goods. Usually could ready within 10 working day, when dispatch, will inform client and send the documents for client making import customs clearance.



FAQ 5. What quality will be ensured?

100% new and quality inspection before delivery from factory.

Stable export box for good package.



FAQ 6. Can you guide the working?

The machine will deliver with English display, English manual and video for installation and operation.



FAQ 7. How can your engineer replace parts if they are not beside the machine?

Bonnin’s engineer could provide the solutions by email and video. In warranty period, we can send spare parts for free and life-time technical support for spare supply.
