CIC-D160 Ion Exchange Chromatography Instruments Machine 42MPa 150W

Basic Information
Place of Origin: Wuhan, China
Brand Name: BonninTech
Certification: CE, ISO
Model Number: CIC-D160
Minimum Order Quantity: 1 set
Price: USD8000-19800/set
Packaging Details: Standard export carton box
Delivery Time: 5-10 days
Payment Terms: T/T
Supply Ability: 100 sets/month
Type: High-pressure And Low-pulse Two-piston Tandem Advection Pump Maximum Pressure: 42MPa
Injector's Maximum Pressure: 35MPa Display: PC Software Controlled
High Light:

CIC-D160 Chromatography Instruments

,

42MPa ion chromatography instrument

,

150W ion exchange chromatography machine

CIC-D160 Laboratory Ion Chromatography Ion-Exchange Chromatography System



CIC-D160 is a high-stability ion chromatograph with upgraded circuit technology ,which can detect anion, cation, cyanide, iodide, sugar and small molecular organic acids . It is widely used in the fields of environment, disease control, food, chemical industry, electronics, mining and metallurgy.



Advantages:

Built-in eluent generator, free from configuring eluent, with gradient elution available
High pressure resistance, small dead volume, highly responsive to signals

Built-in low-pressure degassing technology to eliminate bubble interference for stability
High pressure resistance, small dead volume, highly responsive to signals

Modular design, convenient to assemble and disassemble , easy to operate Optional intelligent automatic injection system for large sample volumes, which features automatic dilution to save labor and time Work across a variety of detectors, to expand the scope of applications of ion chromatography


Pump
Maximum Pressure: 42 MPa
Pressure Display Accuracy: ≤0.1MPa
Flow Rate Range:0.001~9.999mL/min



Built-in Eluent Generator
Eluent Types : KOH/NaOH
Eluent Concentration Range : 0.1-100mM
Concentration Increment : 0.1mM
Flow Rate Range: 0.1-5.0mL/min
Pressure: ≤30MPa



Conductivity Detector
Cell Volume: ≤0.8μL
Detection Range: 0~50000μS/cm
Detection Resolution:≤0.0020nS/cm
Electronic Noise:0.02nS
Temperature Range:
Room temperature+5~60℃(41 ~140℉)
Maximum Pressure:10.0MPa



Others
Power Requirements:150W
Dimensions(L*W*H*):350*470*650 (mm)
Net Weight(KGS):34
Gross Weight(KGS): 40

CIC-D160 Ion Exchange Chromatography Instruments Machine 42MPa 150W 0

CIC-D160 Ion Exchange Chromatography Instruments Machine 42MPa 150W 1CIC-D160 Ion Exchange Chromatography Instruments Machine 42MPa 150W 2

CIC-D160 Ion Exchange Chromatography Instruments Machine 42MPa 150W 3

FAQ 1. Are you a factory or trading company?

We are a factory.



FAQ 2. Can you supply OEM?

OEM is available.



FAQ 3. What's the MOQ ?

(1). MOQ is 1 piece. The disposable supplies order usually at least 1 box.



FAQ 4. How about the order processing and lead time?

After order confirmation and receive the advance payment, we will prepare the machines and goods. Usually could ready within 10 working day, when dispatch, will inform client and send the documents for client making import customs clearance.



FAQ 5. What quality will be ensured?

100% new and quality inspection before delivery from factory.

Stable export box for good package.



FAQ 6. Can you guide the working?

The machine will deliver with English display, English manual and video for installation and operation.



FAQ 7. How can your engineer replace parts if they are not beside the machine?

Bonnin’s engineer could provide the solutions by email and video. In warranty period, we can send spare parts for free and life-time technical support for spare supply.
