DSC-600 DSC Differential Scanning Calorimetry TGA DTA DSC Analyzer

Basic Information
Place of Origin: Wuhan, China
Brand Name: BonninTech
Certification: CE, ISO
Model Number: DSC-600, DSC-1000
Minimum Order Quantity: 1 set
Price: USD4000-8000/set
Packaging Details: Standard export carton box
Delivery Time: 5-10 days
Payment Terms: T/T
Supply Ability: 200 sets/month
Equipment Name: Plastic DSC Differential Scanning Calorimeter DSC Range: DSC Range: 0 ~ ± 600mW
Temperature Range: Room Temperature ~ 600 ℃ Warranty Time: 12 Months And Life-time Technical Support
Highlight:

dsc differential scanning calorimetry

,

Differential Scanning Calorimetry Testing lab

,

DTA dsc instrument

Application areas

The differential scanning calorimeter is designed for the measurement of DSC thermal analysis in plastics and rubber industry, can be glass transition temperature test, phase transition test, melting and enthalpy test, product stability, oxidation induction test, etc. (Tg, Tc, Tm, enthalphy of crystallization, enthalphy of melting & crystallinity in %, OIT, etc). This instruments conforming to national standards GB / T 19466.2 - 2004 / ISO 11357-2: 1999 Part 2: Determination of glass transition temperature, GB / T 19466.3 - 2004 / ISO 11357-3: 1999 Part 3: Melting and crystallization temperature and Determination of enthalpy. Oxidation Induction Time (OIT), which is a measure of the time taken for the sample to start an autocatalytic oxidation reaction at elevated temperatures (200 degrees Celsius) and is an indicator of the ability of the material to resist thermal degradation during forming, storage, welding, and use. ISO 11357-3: 1999, Part 6 Oxidation induction period. Oxidation induction time (isothermal OIT) and oxidation induction temperature (dynamic OIT) determination. Oxidation induction period has been included in the pipeline industry and wire and cable inspection range.



Instrument principle

Differential scanning calorimetry is under the control of the program temperature, the measurement of material and reference power between the temperature difference with a change in technology. The DSC series differential scanning calorimeter is mainly composed of heating furnace, host, microvolt amplifier, A / D converter, data acquisition system, gas flow control system, computer, printer and other components, and supplemented by two atmosphere The measurement results are processed by a computer data processing system.



Main feature

Technical parameter

DSC range 0~±500mW Temperature range

Room

temperature

~500℃/800℃/1500℃

Heating rate 0.1~80℃/min Temperature resolution 0.01℃
Temperature accuracy ±0.1℃ Temperature repeatability ±0.1℃
DSC accuracy ±2% DSC resolution 0.01mW
DSC resolution 0.01mW Temperature control method

Constant

temperature, programs control

automatically

Temperature

control mode

Rise in temperature Atmosphere control of gas

Nitrogen,oxygen

(instrument

changes

automatically)

Gas flow 0-200mL/min Gas pressure 0.2MPa

Accuracy of

gas flow

0.2mL/min Matching crucible

Alumina crucible

Φ6.7*3mm

Standard

sample

Equipped with standardmaterial

(indium ,tin, zinc)

the user can correct the

temperature and enthalpy

Data communication interface

standard USB

interface

Display

method

24bit color,7 inch touch

screen

Power supply

AC220V

50Hz/60Hz

Size

(W * D * H)

42*38*27cm Net weight 14.5KG
Packing size (W * D * H) 58*45*40cm Gross weight 23.5KG

DSC-600 DSC Differential Scanning Calorimetry TGA DTA DSC Analyzer 0

DSC-600 DSC Differential Scanning Calorimetry TGA DTA DSC Analyzer 1

FAQ 1. Are you a factory or trading company?

We are a factory.



FAQ 2. Can you supply OEM?

OEM is available.



FAQ 3. What's the MOQ ?

(1). MOQ is 1 piece. The disposable supplies order usually at least 1 box.



FAQ 4. How about the order processing and lead time?

After order confirmation and receive the advance payment, we will prepare the machines and goods. Usually could ready within 10 working day, when dispatch, will inform client and send the documents for client making import customs clearance.



FAQ 5. What quality will be ensured?

100% new and quality inspection before delivery from factory.

Stable export box for good package.



FAQ 6. Can you guide the working?

The machine will deliver with English display, English manual and video for installation and operation.



FAQ 7. How can your engineer replace parts if they are not beside the machine?

Bonnin’s engineer could provide the solutions by email and video. In warranty period, we can send spare parts for free and life-time technical support for spare supply.
