Pharmacy Medical Vaccine Lab Refrigerator Freezer CFC Free YC 315L

Basic Information
Place of Origin: Wuhan, China
Brand Name: BonninTech
Certification: CE, ISO
Model Number: YC-315L
Minimum Order Quantity: 1 set
Price: USD2000-5000/set
Packaging Details: Standard export carton box
Delivery Time: 5-10 days
Payment Terms: T/T
Supply Ability: 200 sets/month
Incubator Name: Vaccine Refrigerator Temperature: 2℃~8℃
Capacity(L): 315 Internal Size(W*D*H)mm: 580*533*1122
High Light:

YC 315L Lab Refrigerator Freezer

,

pharmacy vaccine fridge CFC free

,

315L medical refrigerator freezer

2℃~8℃ Pharmacy Medical Fridge Refrigerator‎, Lab Vaccine Refrigerator YC-315L





Applications:

This 2 to 8 degree medical refrigerator YC-315L is suitable for storage of biological products, vaccines, drugs, reagents, and more. You can apply the lab / pharmacy fridge in pharmaceutical factories, hospital, centers for disease prevention and control, clinics, and others.



Features:

100% CFC free refrigerant design with no ozone-damaging chemicals for environmental friendly.

Seven temperature probes can ensure highprecision of temperature control with nearly no fluctuation and thus canimprove safety.

The interior lighting system with double LED lights ensures high visibility inside the cabinet.

A test port is available for bringingconvenience to users in testing temperature inside the cabinet.

With a U-disk connected, the temperaturedata can be stored continuously and automatically, in more than 2 years.

Equipped with a USB export interface, whichcan be used for storing data from the last month to the current monthautomatically in PDF format.

Large capacity of 315L for maximum storage convenience to store vaccine, drugs, reagents, and other lab medical materials.





Model Specification:

2~8℃ Pharmacy Vaccines Refrigerator
Model YC-315L
Capacity(L) 315
Internal Size(W*D*H)mm 580*533*1122
External Size(W*D*H)mm 650*673*1762
Package Size(W*D*H)mm 717*732*1785
NW/GW(Kgs) 87/99
Performance
Temperature Range 2~8℃
Ambient Temperature 16-32℃
Cooling Performance 5℃
Climate Class N
Controller Microprocessor
Display Digital display
Refrigeration
Compressor 1pc
Cooling Method Air cooling
Defrost Mode Automatic
Refrigerant R600a
Insulation Thickness(mm) L/R:35,B:52
Construction
External Material Powder coated material
Inner Material HIPS
Shelves 4+1(coated steel wired shelf)
Door Lock with Key Yes
Lighting LED
Access Port 1pc. Ø 25 mm
Casters 4+(2 leveling feet)
Data Logging/Interval/Recording Time USB/Record every 10 minute / 2 years
Door with Heater Yes
Standard Accessory RS485,Remote alarm contact,Backup battery
Alarm
Temperature High/Low temperature,High ambient temperature,Condenser overheating
Electrical Power failure , Low battery,
System Sensor failure,Door ajar,Built-in datalogger USB Failure,Communication failure
Electrical
Power Supply(V/HZ) 220~240/50
Rated Current(A) 1.35
Options Accessory
Optional Printer,RS232





Pharmacy Medical Vaccine Lab Refrigerator Freezer CFC Free YC 315L 0Pharmacy Medical Vaccine Lab Refrigerator Freezer CFC Free YC 315L 1

Pharmacy Medical Vaccine Lab Refrigerator Freezer CFC Free YC 315L 2

FAQ 1. Are you a factory or trading company?

We are a factory.



FAQ 2. Can you supply OEM?

OEM is available.



FAQ 3. What's the MOQ ?

(1). MOQ is 1 piece. The disposable supplies order usually at least 1 box.



FAQ 4. How about the order processing and lead time?

After order confirmation and receive the advance payment, we will prepare the machines and goods. Usually could ready within 10 working day, when dispatch, will inform client and send the documents for client making import customs clearance.



FAQ 5. What quality will be ensured?

100% new and quality inspection before delivery from factory.

Stable export box for good package.



FAQ 6. Can you guide the working?

The machine will deliver with English display, English manual and video for installation and operation.



FAQ 7. How can your engineer replace parts if they are not beside the machine?

Bonnin’s engineer could provide the solutions by email and video. In warranty period, we can send spare parts for free and life-time technical support for spare supply.
